High Strength Grade 4 8 10 12 Steel Black Oxide DIN 935 Castle Nuts
-
High Strength Grade 4 8 10 12 Steel Galvanized Blue White Zinc Plated DIN935 Castle Nuts
MOQ: Contact usPrice: Contact us -
High Strength Grade 4 8 10 12 Steel Color Yellow Zinc Plated DIN935 Castle Nuts
MOQ: Contact usPrice: Contact us -
Stainless Steel A2-70 A4-80 SS201 SS304 SS316 DIN935 Castle Nuts
MOQ: Contact usPrice: Contact us
Product Photos and Information
| Name | Castle Nuts |
| Standards | DIN ISO ANC BSW JIS etc. |
| Size | M3-M50 |
| Length | 8-32 |
| Materials | Carbon Steel/Stainless Steel |
| Strength level | 4 5 8 10 12 A2-70 A4-70 A4-80 etc. |
| Surface finish | ZPHDGBLACKDacromet etc. |
| Samples | Subject to availability and agreement |
Product Standards
| Hexagonal Slotted Nuts DIN 935 | ||||||||||||||
| thread size | M4 | M5 | M6 | (M7) | M8 | M10 | M10 | M12 | M12 | (M14) | (M14) | M16 | ||
| d | ||||||||||||||
| P | Pitch (coarse) | 0.7 | 0.8 | 1 | 1 | 1.25 | 1.5 | 1.5 | 1.75 | 1.75 | 2 | 2 | 2 | |
| fine teeth | - | - | - | - | 1 | 1.25 | 1.25 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | ||
| fine teeth | - | - | - | - | - | 1 | 1 | 1.25 | 1.25 | - | - | - | ||
| d a | minimum | 4 | 5 | 6 | 7 | 8 | 10 | 10 | 12 | 12 | 14 | 14 | 16 | |
| maximum value | 4.6 | 5.75 | 6.75 | 7.75 | 8.75 | 10.8 | 10.8 | 13 | 13 | 15.1 | 15.1 | 17.3 | ||
| from _ | maximum value | / | / | / | / | / | / | / | 16 | 17 | 18 | 19 | twenty two | |
| minimum | / | / | / | / | / | / | / | 15.57 | 16.57 | 17.57 | 18.48 | 21.48 | ||
| dw | minimum | 5.8 | 6.8 | 8.8 | 9.5 | 11.3 | 14.3 | 15.3 | 16.2 | 17.2 | 19.2 | 20.2 | 22.2 | |
| and | minimum | 7.66 | 8.79 | 11.05 | 12.12 | 14.38 | 17.77 | 18.9 | 20.03 | 21.1 | 23.35 | 24.49 | 26.75 | |
| m | max = nominal | 5 | 6 | 7.5 | 8 | 9.5 | 12 | 12 | 15 | 15 | 16 | 16 | 19 | |
| minimum | 4.7 | 5.7 | 7.14 | 7.64 | 9.14 | 11.57 | 11.57 | 14.57 | 14.57 | 15.57 | 15.57 | 18.48 | ||
| m 1 | 2.3 | 3 | 3.8 | 4.2 | 4.9 | 6.1 | 6.1 | 7.7 | 7.7 | 8.2 | 8.2 | 9.8 | ||
| n | minimum | 1.2 | 1.4 | 2 | 2 | 2.5 | 2.8 | 2.8 | 3.5 | 3.5 | 3.5 | 3.5 | 4.5 | |
| maximum value | 1.45 | 1.65 | 2.25 | 2.25 | 2.75 | 3.05 | 3.05 | 3.8 | 3.8 | 3.8 | 3.8 | 4.8 | ||
| s | max = nominal | 7 | 8 | 10 | 11 | 13 | 16 | 17 | 18 | 19 | twenty one | twenty two | twenty four | |
| minimum | 6.78 | 7.78 | 9.78 | 10.73 | 12.73 | 15.73 | 16.73 | 17.73 | 18.67 | 20.67 | 21.67 | 23.67 | ||
| in | minimum | 2.9 | 3.7 | 4.7 | 5.2 | 6.14 | 7.64 | 7.64 | 9.64 | 9.64 | 10.57 | 10.57 | 12.57 | |
| maximum value | 3.2 | 4 | 5 | 5.5 | 6.5 | 8 | 8 | 10 | 10 | 11 | 11 | 13 | ||
| Type ② | Cotter pins according to DIN 94 | 1x10 | 1.2x12 | 1.6x14 | 1.6x14 | 2x16 | 2.5x20 | 2.5x20 | 3.2x22 | 3.2x22 | 3.2x25 | 3.2x25 | 4x28 | |
| Thousand pieces (steel)≈kg | 1.12 | 2.3 | 3.16 | 3.96 | 7.35 | 15.8 | 15.8 | 20 | 20 | 27 | 27 | 38.9 | ||
| thread size | (M18) | M20 | (M22) | (M22) | M24 | (M27) | M30 | (M33) | M36 | (M39) | M42 | (M45) | ||
| d | ||||||||||||||
| P | Pitch (coarse) | 2.5 | 2.5 | 2.5 | 2.5 | 3 | 3 | 3.5 | 3.5 | 4 | 4 | 4.5 | 4.5 | |
| fine teeth | 1.5 | 2 | 1.5 | 1.5 | 2 | 2 | 2 | 2 | 3 | 3 | 3 | 3 | ||
| fine teeth | 2 | 1.5 | 2 | 2 | - | - | - | - | - | - | - | - | ||
| d a | minimum | 18 | 20 | twenty two | twenty two | twenty four | 27 | 30 | 33 | 36 | 39 | 42 | 45 | |
| maximum value | 19.5 | 21.6 | 23.8 | 23.8 | 25.9 | 29.2 | 32.4 | 35.6 | 38.9 | 42.1 | 45.4 | 48.6 | ||
| from _ | maximum value | 25 | 28 | 30 | 32 | 34 | 38 | 42 | 46 | 50 | 55 | 58 | 62 | |
| minimum | 24.3 | 27.3 | 29.3 | 31 | 33 | 37 | 41 | 45 | 49 | 53.8 | 56.8 | 60.8 | ||
| dw | minimum | 24.8 | 27.7 | 29.5 | 31.3 | 33.2 | 38 | 42.7 | 46.6 | 51.1 | 55.9 | 60.6 | 64.7 | |
| and | minimum | 29.56 | 32.95 | 35.03 | 37.29 | 39.55 | 45.2 | 50.85 | 55.37 | 60.79 | 66.44 | 71.3 | 76.95 | |
| m | max = nominal | twenty one | twenty two | 26 | 26 | 27 | 30 | 33 | 35 | 38 | 40 | 46 | 48 | |
| minimum | 20.16 | 21.16 | 25.16 | 25.16 | 26.16 | 29.16 | 32 | 34 | 37 | 39 | 45 | 47 | ||
| m 1 | 11.2 | 11.9 | 13.5 | 13.5 | 14.2 | 16.6 | 18.2 | 19.8 | 21.9 | 23.5 | 25.9 | 27.5 | ||
| n | minimum | 4.5 | 4.5 | 5.5 | 5.5 | 5.5 | 5.5 | 7 | 7 | 7 | 7 | 9 | 9 | |
| maximum value | 4.8 | 4.8 | 5.8 | 5.8 | 5.8 | 5.8 | 7.36 | 7.36 | 7.36 | 7.36 | 9.36 | 9.36 | ||
| s | max = nominal | 27 | 30 | 32 | 34 | 36 | 41 | 46 | 50 | 55 | 60 | 65 | 70 | |
| minimum | 26.16 | 29.16 | 31 | 33 | 35 | 40 | 45 | 49 | 53.8 | 58.8 | 63.1 | 68.1 | ||
| in | minimum | 14.57 | 15.57 | 17.57 | 17.57 | 18.48 | 21.48 | 23.48 | 25.48 | 28.48 | 30.28 | 33.38 | 35.38 | |
| maximum value | 15 | 16 | 18 | 18 | 19 | twenty two | twenty four | 26 | 29 | 31 | 34 | 36 | ||
| Type ② | Cotter pins according to DIN 94 | 4x32 | 4x36 | 5x36 | 5x36 | 5x40 | 5x45 | 6.3x50 | 6.3x56 | 6.3x63 | 6.3x71 | 8x71 | 8x80 | |
| Thousand pieces (steel)≈kg | 57.5 | 75.2 | 93 | 93 | 131 | 192 | 264 | 333 | 447 | 584 | 710 | 860 | ||
| thread size | M48 | (M52) | M56 | (M60) | M64 | (M68) | M72 | (M76) | M80 | (M85) | M90 | M100 | ||
| d | ||||||||||||||
| P | Pitch (coarse) | 5 | 5 | 5.5 | 5.5 | 6 | 6 | - | - | - | - | - | - | |
| fine teeth | 3 | 3 | 4 | 4 | 4 | 4 | 6 | 6 | 6 | 6 | 6 | 6 | ||
| fine teeth | - | - | - | - | - | - | 4 | 4 | 4 | 4 | 4 | 4 | ||
| d a | minimum | 48 | 52 | 56 | 60 | 64 | 68 | 72 | 76 | 80 | 85 | 90 | 100 | |
| maximum value | 51.8 | 56.2 | 61 | 64.8 | 69.1 | 73.4 | 77.8 | 82.1 | 86.4 | 91.8 | 97.2 | 108 | ||
| from _ | maximum value | 65 | 70 | 75 | 80 | 85 | 90 | 95 | 100 | 105 | 110 | 120 | 130 | |
| minimum | 63.8 | 68.8 | 73.8 | 78.8 | 83.6 | 88.6 | 93.6 | 98.6 | 103.6 | 108.6 | 118.6 | 128.4 | ||
| dw | minimum | 69.4 | 74.2 | 78.7 | 83.4 | 88.2 | 92.9 | 97.7 | 102.4 | 107.2 | 111.9 | 121.1 | 135.4 | |
| and | minimum | 82.6 | 88.25 | 93.56 | 99.21 | 104.86 | 110.51 | 116.16 | 121.81 | 127.46 | 133.11 | 144.08 | 161.02 | |
| m | max = nominal | 50 | 54 | 57 | 63 | 66 | 69 | 73 | 76 | 79 | 88 | 92 | 100 | |
| minimum | 49 | 52.8 | 55.8 | 61.8 | 64.8 | 67.8 | 71.8 | 74.8 | 77.8 | 86.6 | 90.6 | 98.6 | ||
| m 1 | 29.1 | 32.3 | 34.7 | 37.1 | 39.3 | 41.7 | 44.9 | 47.3 | 49.7 | 52.9 | 56.1 | 62.5 | ||
| n | minimum | 9 | 9 | 9 | 11 | 11 | 11 | 11 | 11 | 11 | 14 | 14 | 14 | |
| maximum value | 9.36 | 9.36 | 9.36 | 11.43 | 11.43 | 11.43 | 11.43 | 11.43 | 11.43 | 14.43 | 14.43 | 14.43 | ||
| s | max = nominal | 75 | 80 | 85 | 90 | 95 | 100 | 105 | 110 | 115 | 120 | 130 | 145 | |
| minimum | 73.1 | 78.1 | 82.8 | 87.8 | 92.8 | 97.8 | 102.8 | 107.8 | 112.8 | 117.8 | 127.5 | 142.5 | ||
| in | minimum | 37.38 | 41.38 | 44.38 | 47.38 | 50.26 | 53.26 | 57.26 | 60.26 | 63.26 | 67.26 | 71.26 | 79.26 | |
| maximum value | 38 | 42 | 45 | 48 | 51 | 54 | 58 | 61 | 64 | 68 | 72 | 80 | ||
| Type ② | Cotter pins according to DIN 94 | 8x80 | 8x90 | 8x100 | 10x100 | 10x100 | 10x112 | 10x112 | 10x125 | 10x140 | 13x140 | 13x140 | 13x160 | |
| Thousand pieces (steel)≈kg | 1060 | 1300 | 1500 | 1800 | 2150 | 2500 | 2900 | 3300 | 3700 | 4100 | 5450 | 7600 | ||
| ①, Number of slots: | ||||||||||||||
| ≤M39: 6 slots | ||||||||||||||
| M42~M68: 8 slots | ||||||||||||||
| ≥M72: 10 slots | ||||||||||||||
| ②, the length of the split pin is for reference only | ||||||||||||||
