Fastener supplier 304 stainless steel stud high strength Galvanized Full thread stud
-
DIN508 Zinc Plated Steel Stainless Steel T Nuts
MOQ: Contact usPrice: Contact us -
Grade 4.8 Carbon Steel DIN931 DIN933 Hot Dip Galvanized HDG Hex Bolts
MOQ: Contact usPrice: Contact us -
High Strength Grade 4 8 10 12 Steel Galvanized Blue White Zinc Plated DIN6923 Hex Flange Nuts
MOQ: Contact usPrice: Contact us -
High Strength Grade M3-M8 Plate nut for drones Single ear plate nut
MOQ: Contact usPrice: Contact us -
High Strength Grade 8.8 10.9 12.9 Steel DIN931 DIN933 Zinc Plated Hex Bolts
MOQ: Contact usPrice: Contact us -
Cross recessed countersunk head tapping screws High strength galvanized flat head self-tapping screw
MOQ: Contact usPrice: Contact us
Product Photos and Information
| Name | Stud Bolts | Materials | Carbon Steel/Stainless Steel |
| Standards | DIN ISO ANC BSW JIS etc. | Strength level | 4.8 8.8 10.9 12.9 A2-70 A4-70 A4-80 |
| Size | M3-M52 | Surface finish | ZPHDGBLACKDacromet etc. |
| Length | 20-3000 | Samples | Subject to availability and agreement |
Product Standards
| Stud Bolts Thick shank double-ended bolt b1=1d DIN 938 | ||||||||||||||||
| Thread specification | M3 | M4 | M5 | M6 | (M7) | M8 | M10 | M12 | (M14) | M16 | (M18) | M20 | ||||
| d | ||||||||||||||||
| P | pitch | coarse teeth | 0.5 | 0.7 | 0.8 | 1 | 1 | 1.25 | 1.5 | 1.75 | 2 | 2 | 2.5 | 2.5 | ||
| fine teeth 1 | - | - | - | - | - | 1 | 1.25 | 1.25 | 1.5 | 1.5 | 1.5 | 1.5 | ||||
| fine teeth 2 | - | - | - | - | - | - | - | 1.5 | - | - | - | - | ||||
| b 1 | 3 | 4 | 5 | 6 | 7 | 8 | 10 | 12 | 14 | 16 | 18 | 20 | ||||
| b | L≤125 | 12 | 14 | 16 | 18 | 20 | twenty two | 26 | 30 | 34 | 38 | 42 | 46 | |||
| 125＜L≤200 | 18 | 20 | twenty two | twenty four | 26 | 28 | 32 | 36 | 40 | 44 | 48 | 52 | ||||
| L＞200 | - | - | - | - | - | - | 45 | 49 | 53 | 57 | 61 | 65 | ||||
| x 1 | 1.25 | 1.75 | 2 | 2.5 | 2.5 | 3.2 | 3.8 | 4.3 | 5 | 5 | 6.3 | 6.3 | ||||
| x 2 | 0.7 | 0.9 | 1 | 1.25 | 1.25 | 1.6 | 1.9 | 2.2 | 2.5 | 2.5 | 3.2 | 3.2 | ||||
| Thousand pieces of steel weight ≈kg | - | - | - | - | - | - | - | - | - | - | - | - | ||||
| Thread specification | (M22) | M24 | (M27) | M30 | (M33) | M36 | (M39) | M42 | (M45) | M48 | (M52) | |||||
| d | ||||||||||||||||
| P | pitch | coarse teeth | 2.5 | 3 | 3 | 3.5 | 3.5 | 4 | 4 | 4.5 | 4.5 | 5 | 5 | |||
| fine teeth 1 | 1.5 | 2 | 2 | 2 | 2 | 3 | 3 | 3 | 3 | 3 | 3 | |||||
| fine teeth 2 | - | - | - | - | - | - | - | - | - | - | - | |||||
| b 1 | twenty two | twenty four | 25 | 30 | 32 | 35 | 38 | 42 | 45 | 48 | 52 | |||||
| b | L≤125 | 50 | 54 | 60 | 66 | 72 | 78 | 84 | 90 | 96 | 102 | 110 | ||||
| 125<升≤200 | 56 | 60 | 66 | 72 | 78 | 84 | 90 | 96 | 102 | 108 | 116 | |||||
| L>200 | 69 | 73 | 79 | 85 | 91 | 97 | 103 | 109 | 115 | 121 | 129 | |||||
| x 1 | 6.3 | 7.5 | 7.5 | 9 | 9 | 10 | 10 | 11 | 11 | 12.5 | 12.5 | |||||
| x 2 | 3.2 | 3.8 | 3.8 | 4.5 | 4.5 | 5 | 5 | 5.5 | 5.5 | 6.3 | 6.3 | |||||
| The weight of one thousand pieces of steel ≈ kilograms | - | - | - | - | - | - | - | - | - | - | - | |||||
About Us
YONGYI Fasteners supports industrial and project fastener inquiries from Yongnian, Handan, China.
Our published company certificates, factory photographs, production information and selected supply references help buyers evaluate manufacturing and quality-control capabilities.
For a quotation, provide the product standard or drawing, size, material or grade, surface finish, quantity, packing requirement and destination.
