Flange bolt 4.8 Grade Metal Hex Head Flange Bolt, Metric Hexagon Head Cap Yellow Zinc Plated

Name: Flange bolt 4.8 Grade Metal Hex Head Flange Bolt, Metric Hexagon Head Cap Yellow Zinc Plated
Brand: YONGYI

Category:

Products

Bolt

Email:

sales@yyfasteners.com

Get Quote

Products Description:

Bolts provide controlled clamping for machinery, construction, steel structures and OEM assemblies. Select the head style, thread, standard, material, property class and surface finish according to the joint design and service environment. It must be carefully if substituting a headed bolt for threaded bar and nuts because there will usually be a reduction in strength. A threaded rod, also called as astud, is a relatively long rod that is threaded on both ends; the thread may extend along the complete length of the rod.They are designed to be used in tension. Threaded rod in bar stock form is often called all-thread. Threaded rod provides a means of hanging or suspending strut, conduit systems, piping, etc. The Threaded rods are used to building fasteners with standard thread. It can be drilled into the nut and equipped with a connecting nut, a fixed mounted component is fixed at the opposite side of the rod. Stainless Threaded Rod is specifically designed for general purpose fixing and shade sail applications. Threaded Rods are designed for situations when fast assembly and disassembly are required.

Specification

Items	Size	Grade	Grade
DIN 933 Full thread	M6*16	4.8	8.8
DIN 933 Full thread	M6*25	4.8	8.8
DIN 933 Full thread	M6*30	4.8	8.8
DIN 933 Full thread	M6*50	4.8	8.8
DIN 933 Full thread	M8*20	4.8	8.8
DIN 933 Full thread	M8*40	4.8	8.8
DIN 933 Full thread	M10*20	4.8	8.8
DIN 933 Full thread	M10*100	4.8	8.8
DIN 933 Full thread	M16*50	4.8	8.8
DIN 931 Half thread	M6*16	4.8	8.8
DIN 931 Half thread	M6*30	4.8	8.8
DIN 931 Half thread	M8*25	4.8	8.8
DIN 931 Half thread	M8*50	4.8	8.8
DIN 931 Half thread	M10*100	4.8	8.8
DIN 931 Half thread	M12*50	4.8	8.8
DIN 931 Half thread	M12*100	4.8	8.8
DIN 931 Half thread	M14*100	4.8	8.8
DIN 931 Half thread	M16*100	4.8	8.8
DIN 931 Half thread	M18*100	4.8	8.8
Flange Bolts Full thread	M8*20	4.8	8.8
Flange Bolts Full thread	M8*80	4.8	8.8
Flange Bolts Full thread	M10*40	4.8	8.8
Flange Bolts Full thread	M10*90	4.8	8.8
Flange Bolts Half thread	M8*40	4.8	8.8
Flange Bolts Half thread	M8*80	4.8	8.8
Flange Bolts Half thread	M10*16	4.8	8.8
Flange Bolts Half thread	M10*90	4.8	8.8

Ordering and Documentation

Confirm the product standard or drawing, thread and dimensions, material or property class, surface finish, quantity, packing and destination before quotation.

Required inspection, material, mechanical-property, coating and packing documents must be listed in the inquiry. Availability, lead time and commercial terms are confirmed for the specific order.

Send YONGYI your purchase list or drawing.

Key word:
- Flange-bolt
- Cap bolt
- Hex Bolt

Get Quote

NOTE: Please leave your email, our professional person will contact you asap!

SUBMIT

Flange bolt 4.8 Grade Metal Hex Head Flange Bolt, Metric Hexagon Head Cap Yellow Zinc Plated Specifications

Product FamilyFlange Bolts

StandardConfirm by drawing or purchase specification

MaterialMaterial to be confirmed with the order

FinishYellow zinc plated

YONGYI supplies Flange bolt 4.8 Grade Metal Hex Head Flange Bolt, Metric Hexagon Head Cap Yellow Zinc Plated for industrial, OEM and project purchasing. This page identifies the requested product family, standard, material, grade and finish so buyers can compare it with their drawing, bill of materials or technical specification.

Standard designations are common market references. Final dimensions, tolerances, mechanical properties, coating requirements and thread fit are confirmed in the quotation or approved drawing before production.

Product	Flange bolt 4.8 Grade Metal Hex Head Flange Bolt, Metric Hexagon Head Cap Yellow Zinc Plated
Category	Bolts / Flange Bolts
Referenced Standard	Confirm by drawing or purchase specification
Size / Thread	Confirm nominal size, thread and length with the inquiry
Material	Material to be confirmed with the order
Grade / Property	4.8
Surface Finish	Yellow zinc plated
Packaging	Carton, bag, pallet or project-specific export packing after quantity and unit weight are confirmed.

Typical Applications

Steel structures, machinery and industrial equipment assemblies
OEM production and maintenance fastening requirements
Project supply with specified grade, coating, packing and documentation

Information Required for an Accurate Quote

Nominal diameter, thread system, pitch and length where applicable
Required standard, material and property class or hardness
Surface finish, coating standard and any thickness or corrosion requirement
Order quantity, packing method, destination and required supporting documents

Quality and Order Documentation

Depending on the agreed order and available production records, documentation may include an approved drawing, dimensional inspection, material or mechanical-property report, coating report, packing list and shipment photos. Required documents must be stated before quotation.

FAQ

Can this product be supplied to a drawing?	Drawing-based and sample-based requirements can be reviewed. Feasibility, tolerances, tooling, MOQ and lead time are confirmed after technical review.
How should I request an alternative standard?	Send the original specification and identify any acceptable alternative. YONGYI will list confirmed compliance and any technical deviation separately.
Can coating and test documents be included?	Yes, when agreed before order. State the coating specification, test scope, inspection party and document format in the inquiry.
