Hot dip galvanized Flat washer M10 - M30 Metal Washers DIN 7989/DIN 125 Standard With Hot Dip Galvanized Finish

Name: Hot dip galvanized Flat washer M10 - M30 Metal Washers DIN 7989/DIN 125 Standard With Hot Dip Galvanized Finish
Brand: YONGYI

Category:

Products

Flat Washer

Email:

sales@yyfasteners.com

Get Quote

Related products

Commodity name： Hot-dip-galvanized-Flat-washer M10 - M30 Metal Washers DIN7989 /DIN125 Standard With Hot Dip Galvanized Finish
Commodity ID： pc_1

Product Description

Hot-dip-galvanized-Flat-washer

Hot-dip-galvanized-Flat-washer M10 - M30 Metal Washers DIN7989 /DIN125

Standard With Hot Dip Galvanized Finish Galvanizing also known as hot dip zinc and hot dip galvanized: is an effective way of metal corrosion, mainly used in various sectors of the metal structure facilities. Is the rust after the steel immersed in about 500 ℃ melting zinc solution, so that the steel surface attached to the zinc layer, which play the purpose of corrosion. Usually, the thickness of the galvanized layer is 5 to 15 m, and the hot-dip galvanizing layer is generally 35 m or more, even up to 200 m. Hot galvanized coverage is good, the coating is dense, no organic inclusions. It is well known that the mechanism of anti-atmospheric corrosion of zinc has mechanical protection and electrochemical protection. Under the atmospheric corrosion conditions, ZnO, Zn (OH) 2 and basic zinc carbonate protective film on the surface of zinc layer can reduce the corrosion of zinc to a certain extent. Layer protective film (also known as white rust) is damaged and will form a new film. When the zinc layer is seriously damaged, threatening the iron matrix, zinc on the substrate to produce electrochemical protection, the standard potential of zinc -0.76V, iron standard potential -0.44V, zinc and iron to form a micro-battery zinc as the anode is dissolved, iron As the cathode is protected. It is clear that the hot-dip galvanizing is superior to galvanized to the atmospheric corrosion resistance of the matrix metal iron.

Welcome to visit our website and send us emails , inquirys and we will give you the response within 24hours. Please feel free to do that, we will give you best service and offer you lower price.

Specification

DIN7989 Flat Washers
SIZE	inside diameter	Outside diameter	thickness	Thousands of heavy
10	11-11.7	18.7-20	8-12	13.8
12	13.5-14.2	22.7-24	8-12	19.4
16	17.5-18.2	28.7-30	8-12	29.3
20	22-22.84	35.4-37	8-12	43.7
24	26-26.84	42.4-44	8-12	62.1
27	30-30.84	48.4-50	8-12	78.9
30	33-34	54.1-56	8-12	101

Ordering and Documentation

Confirm the product standard or drawing, thread and dimensions, material or property class, surface finish, quantity, packing and destination before quotation.

Required inspection, material, mechanical-property, coating and packing documents must be listed in the inquiry. Availability, lead time and commercial terms are confirmed for the specific order.

Send YONGYI your purchase list or drawing.

Key word:
- Hot-dip Flat-washer
- Flat-washer
- Hot-dip-galvanized
- DIN125
- DIN7989

Get Quote

NOTE: Please leave your email, our professional person will contact you asap!

SUBMIT

Hot dip galvanized Flat washer M10 - M30 Metal Washers DIN 7989/DIN 125 Standard With Hot Dip Galvanized Finish Specifications

Product FamilyFlat Washers

StandardDIN 7989, DIN 125

MaterialMaterial to be confirmed with the order

FinishHot-dip galvanized

YONGYI supplies Hot dip galvanized Flat washer M10 - M30 Metal Washers DIN 7989/DIN 125 Standard With Hot Dip Galvanized Finish for industrial, OEM and project purchasing. This page identifies the requested product family, standard, material, grade and finish so buyers can compare it with their drawing, bill of materials or technical specification.

Standard designations are common market references. Final dimensions, tolerances, mechanical properties, coating requirements and thread fit are confirmed in the quotation or approved drawing before production.

Product	Hot dip galvanized Flat washer M10 - M30 Metal Washers DIN 7989/DIN 125 Standard With Hot Dip Galvanized Finish
Category	Washers / Flat Washers
Referenced Standard	DIN 7989, DIN 125
Size / Thread	M10-M30
Material	Material to be confirmed with the order
Grade / Property	Mechanical property requirement to be confirmed
Surface Finish	Hot-dip galvanized
Packaging	Carton, bag, pallet or project-specific export packing after quantity and unit weight are confirmed.

Typical Applications

Load distribution beneath bolt heads and nuts
Joint protection, spacing or locking functions according to washer design
Machinery, steelwork and general industrial fastening assemblies

Information Required for an Accurate Quote

Nominal diameter, thread system, pitch and length where applicable
Required standard, material and property class or hardness
Surface finish, coating standard and any thickness or corrosion requirement
Order quantity, packing method, destination and required supporting documents

Quality and Order Documentation

Depending on the agreed order and available production records, documentation may include an approved drawing, dimensional inspection, material or mechanical-property report, coating report, packing list and shipment photos. Required documents must be stated before quotation.

FAQ

Can this product be supplied to a drawing?	Drawing-based and sample-based requirements can be reviewed. Feasibility, tolerances, tooling, MOQ and lead time are confirmed after technical review.
How should I request an alternative standard?	Send the original specification and identify any acceptable alternative. YONGYI will list confirmed compliance and any technical deviation separately.
Can coating and test documents be included?	Yes, when agreed before order. State the coating specification, test scope, inspection party and document format in the inquiry.
